Long Range UHF RFID Reader
Long Range Control Access Parking Barrier Gate System 1~8M Integrated UHF RFID Reader
Long Range UHF RFID Reader Features
1. Long range 1~8 meters reading distance
2. IP67 waterproof for outdoor use
3. It is standard RS485, Wiegand26 / 34, USB interface, optional RJ45, WIFI, Relay output
4. We provide programmable software to program reading distance, reading interval, frequency flexible
5. Frequency range of 860MHz～ 960MHz to read ISO18000‐6C and ISO18000‐6B protocol ID Tag.
6. Operation mode support Master‐Slave Mode(Online Mode),Time Scheduled Modes,Trigger Mode
7. We provide API Software Development Kits complete with VB,C# Sample Program
8. It is built in with 9dBi circular polarize antenna
Long Range UHF RFID Reader Specification
| Product Name | Long Range UHF RFID Reader |
| Chip |
ARM7+UHF model
|
|
Operating Frequency
|
860~960MHZ |
| Reading Distance | 1~8 meters |
| Group read performance: | 50 tags at same time |
| Protocol | ISO18000-6C(EPC GEN2) |
| Frequency Hopping Mode: | Fixed Frequency Band and FHSS Software Programmable |
| Working Mode | Master‐Slave Mode(Online Mode),Time Scheduled Modes,Trigger Mode |
| Output Power | 0-30dBm(Adjustable) |
| Antenna | 9dBi circular polarize antenna |
| Interface | Standard RS485, Wiegand26, Wiegand34, USB, optional RJ45, WIFI, Relay output |
| Power Supply | 12V |
| Prompt | Beep or LED light flash |
| Operation Temperature | －20℃ ～ +70℃ |
| Dimension | 260x260x60MM |
| SDK/API | API Software Development Kits complete with VB,C#Sample Program |
Long Range UHF RFID Reader Introduction
This UHF RFID reader can be used indoors or outdoors (IP67 degree of protection). It has a maximum reading distance of up to 6 meters range. Its working frequency is standard for international 860~960MHZ. It has reading and writing of CHIP UHF configurable through software. Open protocol for reading existing UHF proximity tags or stickers on the market. Signal gain: 0-30 dBm. Connection: RS-232 / RS-485. Wiegand 26-bit output, USB, RJ45. WiFi, Relay ouput. Works with any access control on the market (anyone that handles a Wiegand protocol as reader connection).
Long Range UHF RFID Reader Application
UHF RFID reader are long-range readers that are mainly used in vehicle access control, they have the ability to read a sticker or tag that is attached to the car, and when it approaches a distance of 1~8 meters open and close the door automatically to grant or deny you access, depending on whether or not you have permission to enter.
Biometric Face Recognition System FAQ
Q1: Are you real manufacturer?
Yes, our factory is based in Shenzhen China and we've been in this industry for 21 years
Q2: How is your after-sales service?
We have after-sales technical team, provide 24 hours online technical support.
Q3: Do you supply OEM service?
Yes, we can customize your logo on machine/boot screen/standby screen/package box. Other customization is negotiable.
Q4: What is your Warranty?
1 year normally.
Our products are sold all over the world, you can rest assured.
