Cloud based biometric recognition wifi time attendance access control System
Linux Based Visible Light Facial and fingerprint Recognition With Wireless WiF
Enhanced Visible Light Facial Recognition with 6 pieces of brighten LED. Masked individual identification increases FAR. Multiple verification methods: Face/Fingerprint/Card/Password. Built-in ID reader of 125KHz, Optional 13.56MHz IC(MF) card. Professional web based management software. Recognition distance: 0.5-2.5 meters.
Face Recognition Machines Features
1) Equipped with 2 million binocular cameras, WDR wide dynamic camera, strong lightdark lightbacklight images are clear, the recognition accuracy is as high as 99.7%; support live detection, dynamic binocular anti-counterfeiting; reject fake faces and photos.
2) The face recognition speed is fast, and the recognition speed is less than 0.2S; it supports on-site snapshot and save portrait photos when the face recognition is successful.
3) A variety of combination authentication methods: support face, card, password authentication; face + card combination authentication; can be flexibly configured according to the scene.
4) Support TTS: smart voice broadcast, after Chinese or English recognition is successful, the voice broadcast personnel name.
5) Support Chinese, English and other 20 national languages and voices; support Chinese, English, Korean, Persian T9 input method.
6) Support local face registration, U disk import photo registration, background software import photo registration.
7) Dual-mode report output: support U disk import and export data package table, support background desktop publishing software, cloud platform statistical data package table.
8) Professional access control function: open the door by time period, open the door by group combination, valid date of the user, etc.; to cooperate with the scene of personnel entering and exiting.
9) The standard version supports portrait recognition, built-in card swiping, password and QR code recognition, and cooperates with the cloud
platform to realize the use of visitor scenarios for outsiders
Face recognition machines Specification
|
Specifications
|
|
|
Product name
|
AI Dynamic Face Recognition Time Attendance Access Control Terminal
|
|
Screen
|
4.3 Inch Capacitive LCD touch screen
|
|
Keypad
|
Touch keypad
|
|
Operation system
|
LINUX 3.10
|
|
CPU,NPU
|
800M single-core ARM Cortex-A7 / 800G (0.8T) Hashrate
|
|
RAM
|
256MB DDR3
|
|
ROM
|
eMMC Flash 4GB
|
|
Binocular camera
|
200W Colorful WDR+200W Infrared live camera
|
|
Logs capacity
|
500,000
|
|
Face Registration
|
Local operation: Enroll face with machine, import user photo with U disk
|
|
Software operation: Import user photo to software, capture user photo with camera
|
|
|
Verification
|
Dynamic face recognition, password, ID/IC card optional
|
|
Face capacity
|
5,000 (20,000 optional)
|
|
Card Capacity
|
ID Card Standard (125 kHz), IC Card Optional (13.56 Mhz)
|
|
Password Capacity
|
15,000 (50000 optional)
|
|
Face Recognition Accuracy
|
99.70%
|
|
Recognition Speed
|
≤0.2s, support single user recognition at same time
|
|
Recognition Distance
|
0.5~2.5 meters (0.5~1.5 meters with live face recognition on)
|
|
Prevent Photo
|
Dual camera anti-counterfeiting, prevent recognition with photo/video
|
|
Principle of Identification
|
Face algorithm technology of multi-task cascaded convolutional neural network based on
|
|
|
video stream for dynamic face detection, tracking and recognition
|
|
WDR
|
Wide dynamic range, support accurate face recognition under Strong light, dark light and backlight
|
|
USB
|
USB2.0x1,Support U disk import/export data
|
|
Power supply
|
DC12V interface x 1
|
|
Speaker Interface
|
Reserved for extended Speaker Interface
|
|
Network Communication
|
TCP/IP, Support C/S LAN communication, Wifi (optional)
|
|
Free Attendance sofware
|
Support exporting excel attendance report with U disk
|
|
Shift
|
Support shift setting and importing shift schedule with U disk
|
|
Management Software
|
Support PC software to manage data through network connection with equipment
|
|
Access Control Function
|
Doorbell output/external ring/alarm (Choose 1 of 3)
|
|
one set of alarm signals, time permission control, connect external access control reader,
|
|
|
Wiegand 26/34 input/output
|
|
|
Environmental adaptability
|
Working temperature: -15C~+45°C (storage temperature -40C~+65°C),
|
|
Working humidity: 20% ~90% (storage humidity 20%~90+2%),
|
|
|
Dark enviroment: LEDSoft light automatic fll light (Automatic control according to ambient light)
|
|
|
Ambient light adaptation range: 0-50000Lux
|
|
|
Muti language
|
English, Spanish, Arabic, Thai, Portuguese, French, Italian, Japanese, Korean, etc
|
|
Broadcase and ring
|
Support display name, voice broadcase name, builtin bell ring
|
|
Automatic fill light
|
Support infrared fill light, the white fll light automatically lights up when face is captured in dark light
|
|
Working Current
|
stand-by current: 310mA , Working current: 520mA
|
|
Working Voltage
|
DC12V
|
|
Installation Way
|
Standard: Wall mount, desktop stand; Optional: bracket for turnstile, floor stand
|
|
Device Dimension
|
125x130x61.7mm
|
|
Color box dimension
|
257x171x90mm
|
|
Carton dimension
|
Size: 480x438x229mm,12Kg/carton, 10 pcs /carton
|
Specification:
Face recognition machines FAQ
Q1: Are you a manufacturer or a trading company?
Reply : Shenzhen Union Timmy Technology Co., Ltd. is one of the leading manufacturers and exporters. We are enjoying an excellent reputation through 23 years of production experience of time attendance in China.
Q2: How many days can we get the products if placed purchase order?
Reply : In regularly, 2-3 working days for Sample and ready stock;
15 working days for production order after receiving of order confirmation and deposit.
Q3: When was your company formed?
Reply : Since year 2000, the founders of Shenzhen Union Timmy Technology Co., Ltd. (Timmy Technology) have been striving for independent research and development of biometric verification algorithms, vertical three roller gates, access control system, one-card management system and the production of biometric verification SDK which was initially widely applied in PC security, time attendance and identity authentication fields.
Q4: Any payment method are acceptable?
Reply: T/T, PayPal and .
Q5: Can we print our brand name for OEM?
Reply: Logo printed and client customization are our expertise for ordering at our MOQ 100 pcs.
Q6: Can we get some samples?
Reply: We are honored to offer samples for your evaluation.
Q7: How does your factory QC?
Reply: Quality check is our first priority for our customers without any careless.
Furthermore, Timmy Technology has been recognized as a "National High-tech Enterprise" for 3 consecutive years, passed ISO9001 certification, and the products have passed FCC/CE/ROHS certification, etc
Should you have any inquiry, feel free to contact us
Face recognition machines Warranty
Timmy warrantees all the hardware products to be free from manufacturing defects. It also warrants this hardware product against defects in materials and workmanship that result in a material deviation from the applicable published Timmy technical specifications or customized specifications for that particular client.
Our products are sold all over the world, you can rest assured.
