HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control

HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control

  • High Light

    5 Inch Face Recognition Machines

    ,

    IP65 Face Recognition Machines

    ,

    IP65 Face Recognition Smart Access Control

  • Screen
    5-inch HD IPS Touch Screen
  • Identification Mode
    1:N, 1:1
  • Identification Speed
    ≦0.2s
  • Face / ID Capacity
    5,000
  • Record Capacity
    500,000
  • Resolution
    1280 X 720
  • Special Features
    Motion Detection, Touch Screen, Built-in Camera, Night Vision (
  • Detection Range
    0.5-3m
  • Screen Resolution
    200WP Dual Infrared, Dual HD Camera
  • Waterroof Rating
    IP-65
  • Wiegand
    1 Set Wiegand 26/34 Input Output
  • Power Supply
    DC 12V 1A
  • Place of Origin
    China
  • Brand Name
    TIMMY
  • Certification
    RoHS, CE, FCC
  • Model Number
    TM-AI01
  • Minimum Order Quantity
    1pcs (sample)
  • Price
    Negotiable
  • Packaging Details
    Export packing: 28*20*17 cm G.W. 2 Kg
  • Delivery Time
    Sample order 2~3 working days; Bulk order 6~12 working days
  • Payment Terms
    T/T, , Payal
  • Supply Ability
    1000 pcs per week

HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control

HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control

Multiple Faces Recognition 5 Inch HD Screen AI based Live Face Recognition Access Control Terminal

TM-AI01 is 5-inch HD IPS Touch Screen, a Real 2 million binocular camera, wide dynamic image recognition, can be recognized under strong light and dark light



Face Recognition Machines Features

  1. Support multi person face recognition with 5 persons at same time (Single person or multi person recognition are selectable)
  2. Support WDR (wide dynamic range), with good performance. It can be detected under a strong light, dark light and backlight environment
  3. Support mask detection (Choose Yes/No in the menu)
  4. Support capture stranger's face if he appears in the camera
  5. Display user enrolled photo when verified face.
  6. Support set face recognition distance: close (around 0.8m), middle (around 1.5m), far (around 2~3m)
  7. Support lock screen, after locking screen, user have to touch the screen to active the machine, then do face recognition. If not touch the screen, even if the user stands in front of machine it not recognizes face.
  8. Support match in server.
  9. Waterproof rating is IP65 which suitable for outdoor installation on turnstile



Face recognition machines Specification





HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 0HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 1HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 2HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 3HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 4HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 5HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 6HD Screen 5 Inch Face Recognition Machines AI Based Live Smart Access Control 7

Specification
Installation Method
Wall mount, Turnstile, Desktop Stand & Floor Stand
CPU Processor
1.2G Dual-Core ARM Cortex-A7
RAM
256M DDR3L
ROM
4G eMMC
NPU
600G(0.6T)
Cabinet raw material
Metal case ( Alumium)
Camera
200W Pixel hd color camera, 200W Infrared camera
LED
LED Double high power infrared light
Display
5" HD 1280*720 IPS touch screen
Communication
TCP/IP, WIFI / USB Type-A
FRR
<0.1%
FAR
<0.0001%
Power supply
DC 12V, 2A
Operating system
LINUX
Language
Multi languages
User capacity
Face: 5,000 (Optional 50,000)
Record Capacity
5,000,000
Identification style
Visible Light Facial Recognition, PIN, face & PIN combination ,ID (Multi detection for 5 users)
Exposure Compensation
*Real 2 million binocular camera, wide dynamic image recognition, can be recognized under strong light and dark light
Identification Mode
1:1, 1:N
Prevent photo
Prevent face recognition with photo/video
Face recognition time
<0.2S
Intelligent function
Live face detection
Detection range
0.5-2.5m(0.5~1.5m with live face recognition on)
Magnetic door
support
Access Control
One set relay output,anti passback, door sensor, doorbell, exit button
Weigand
1 set WG26/34 In, out
Dimension
192*110*20mm
Waterproof rating
IP65



Face recognition machines FAQ



Q1: Are you a manufacturer or a trade company?
Reply : Shenzhen Union Timmy Technology Co., Ltd. is one of the leading manufacturers and exporters. We are enjoying an excellent reputation through 20 years’ production experience of time attendance in China.

Q2: How many days can we get the products if placed purchase order?
Reply : In regularly, 2-3 working days for Sample and ready stock;
15 working days for production order after receiving of order confirmation and deposit.

Q3: When was your company formed?
Reply : Since year 2000, the founders of Shenzhen Union Timmy Technology Co., Ltd. (Timmy Technology) have been striving for independent research and development of biometric verification algorithms, vertical three roller gates, access control system, one-card management system and the production of biometric verification SDK which was initially widely applied in PC security, time attendance and identity authentication fields.



Q4: Any payment method are acceptable?
Reply: T/T, PayPal and .



Q5: Can we print our brand name for OEM?
Reply: Logo printed and client customization are our expertise for ordering at our MOQ.


Q6: Can we get some samples?
Reply: We are honored to offer samples for your evaluation.

Q7: How does your factory QC?
Reply: Quality check is our first priority for our customers without any careless.
Furthermore, Timmy Technology has been recognized as a "National High-tech Enterprise" for 3 consecutive years, passed ISO9001 certification, and the products have passed FCC/CE/ROHS certification, etc




Should you have any inquiry, feel free to contact us





Face recognition machines Warranty



Timmy warrantees all the hardware products to be free from manufacturing defects. It also warrants this hardware product against defects in materials and workmanship that result in a material deviation from the applicable published Timmy technical specifications or customized specifications for that particular client.
