Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System

Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System

  • High Light

    5.0 Inch Face Recognition Machines


    RoHS Face Recognition Machines


    RoHS Time Attendance Access Control System

  • Screen
    5-inch IPS Touch Screen
  • Identification Speed
  • Record Capacity
  • Face / ID Capacity
    5,000 (20,000/50,000 Optional)
  • Resolution
    HD 720P
  • Special Features
    Motion Detection, Built-in Camera, Touch Screen, Night Vision
  • Detection Range
  • Screen Resolution
    200W Pixel Dual Infrared, 200W Pixel Dual HD Camera
  • Wiegand
    1 Set Wiegand Out
  • Power Supply
    DC 12V 1A
  • Place of Origin
    Guandong, China
  • Brand Name
  • Certification
    RoHS, CE, FCC
  • Model Number
  • Minimum Order Quantity
    1pcs (sample)
  • Price
  • Packaging Details
    Export packing: 10 units / Outer Box 575*435*235 mm G.W: 11.80 Kgs
  • Delivery Time
    Sample order 2~3 working days; Bulk order 6~12 working days
  • Payment Terms
    T/T, , Payal
  • Supply Ability
    1000 pcs per week

Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System

Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System


Feature with Multiple-Face Recognition, QR Code, Proximity Card Recognition Access Control.

It is a time attendance and access control machine support face recognition, RFID card, password, 5-inch touch screen, TCP/IP, USB and Wifi.


Face Recognition Machines Features

  1. Support multi-person face recognition with 5 persons at same time (Single person or multi person recognition are selectable)

  2. Support WDR (wide dynamic range), with good performance. It can be detected under a strong light, dark light and backlight environment

  3. Support mask detection (Choose Yes/No in the menu)

  4. Support capture stranger's face if he appears in the camera

  5. Display user enrolled photo when verified face.

  6. Support set face recognition distance: close (around 0.8m), middle (around 1.5m), far (around 2~3m)

  7. Support lock screen, after locking screen, user have to touch the screen to active the machine, then do face recognition. If not touch the screen, even if the user stands in front of machine it not recognizes face.

  8. Support match in server.


Face recognition machines Specification



Product name

AI Dynamic Face Recognition Time Attendance Access Control Terminal


5.0 Inch, HD 1280*720, Capacitive Touch Screen


Touch keypad

Operation system

LINUX 3.10


1.2G Dual-Core ARM Cortex-A7, 600G (0.6T)


256MB DDR3


eMMC Flash 4GB

Binocular camera

200W Colorful WDR+200W Infrared live camera

Logs capacity


Face Registration

Local operation: Enroll face with machine, import user photo with U disk

Software operation: Import user photo to software, capture user photo with camera


Dynamic face recognition, password, ID/IC card optional

Face capacity

5000 (20000/50000 optional)

Card Capacity

5000 (20000/50000 optional), ID Card Standard, IC Card Optional

Password Capacity

5000 (20000/50000 optional)

Face Recognition Accuracy


Recognition Speed

≤0.2s, support single user/multi user(at most 5 users) recognition at same time

Recognition Distance

0.5~2.5 meters (0.5~1.5 meters with live face recognition on)

Prevent Photo

Dual camera anti-counterfeiting, prevent recognition with photo/video

Principle of Identification

Face algorithm technology of multi-task cascaded convolutional neural network based on



video stream for dynamic face detection, tracking and recognition


Wide dynamic range, support accurate face recognition under Strong light, dark light and backlight


USB2.0x1,Support U disk import/export data

Power supply

DC12V interface x 1

Speaker Interface

Reserved for extended Speaker Interface

Network Communication

TCP/IP, Support C/S LAN communication, Wifi (optional)

Free Attendance sofware

Support exporting excel attendance report with U disk


Support shift setting and importing shift schedule with U disk

Management Software

Support PC software to manage data through network connection with equipment

Access Control Function

Door unclosed alarm, forced door opening alarm, alarm linkage and output, one set of door opening signals,

one set of alarm signals, time permission control, connect external access control reader,

Wiegand 26/34 output

Environmental adaptability

Working temperature: -15C~+45°C (storage temperature -40C~+65°C),

Working humidity: 20% ~90% (storage humidity 20%~90+2%),

Dark enviroment: LEDSoft light automatic fll light (Automatic control according to ambient light)

Ambient light adaptation range: 0-50000Lux

Muti language

English, Spanish, Arabic, Thai, Farsi, Portuguese, French, Italian, Japanese, Korean, etc

Broadcase and ring

Support display name, voice broadcase name, builtin bell ring

Automatic fill light

Support infrared fill light, the white fll light automatically lights up when face is captured in dark light

Working Current

stand-by current: 310mA , Working current: 520mA

QR Code Scanner


Working Voltage


Installation Way

Standard: Wall mount, desktop stand; Optional: bracket for turnstile, floor stand

Device Dimension


Color box dimension


Carton dimension

Size: 480x438x229mm,12Kg/carton, 10台 /carton


Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System 0Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System 1Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System 2Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System 3Dynamic 5.0 Inch Face Recognition Machines RoHS Time Attendance Access Control System 4


Face recognition machines FAQ


Q1: Are you a manufacturer or a trade company?
Reply : Shenzhen Union Timmy Technology Co., Ltd. is one of the leading manufacturers and exporters. We are enjoying an excellent reputation through 20 years’ production experience of time attendance in China.

Q2: How many days can we get the products if placed purchase order?
Reply : In regularly, 2-3 working days for Sample and ready stock;
15 working days for production order after receiving of order confirmation and deposit.

Q3: When was your company formed?
Reply : Since year 2000, the founders of Shenzhen Union Timmy Technology Co., Ltd. (Timmy Technology) have been striving for independent research and development of biometric verification algorithms, vertical three roller gates, access control system, one-card management system and the production of biometric verification SDK which was initially widely applied in PC security, time attendance and identity authentication fields.


Q4: Can we print our brand name for OEM?
Reply: Logo printed and client customization are our expertise for ordering at our MOQ.


Q5: Any payment method are acceptable?
Reply: T/T, PayPal and .

Q6: Can we get some samples?
Reply: We are honored to offer samples for your evaluation.

Q7: How does your factory QC?
Reply: Quality check is our first priority for our customers without any careless.
Furthermore, Timmy Technology has been recognized as a "National High-tech Enterprise" for 3 consecutive years, passed ISO9001 certification, and the products have passed FCC/CE/ROHS certification, etc


Should you have any inquiry, feel free to contact us


Face recognition machines Warranty


Timmy warrantees all the hardware products to be free from manufacturing defects. It also warrants this hardware product against defects in materials and workmanship that result in a material deviation from the applicable published Timmy technical specifications or customized specifications for that particular client.
